Encoder 30W DC Worm Geared Motor High Torque 12V Motors Self Locking

30W DC Worm Geared Motor Encoder 24V 12V High Torque Electric 12-470RPM Self Locking Adjustable Speed

Now ,you can get our this worm gearbox dc gear motor and other related worm gearbox motors as following:

JGY-370	JGY-395	JGY-385	5840-31ZY
5840-3650	5840-555	JGY-2430	5882-4260

Specification:

• ① The name of the motor: DC Worm Geared Motor With Encoder

  ② The voltage you can choose for this motor is DC 12V And DC 24V

  ③ After you select the voltage of the motor, you can choose one of the following speeds to purchase. The following speeds refer to the no-load speed of the motor, not the load speed;

  For example, 12RPM means that the motor rotates 12 times per minute without load.

  DC 12V ; You can choose the no load speed have :
  12rpm/27rpm/40rpm/80rpm/160rpm/260rpm/470rpm

  DC 24V ; You can choose the no load speed have :
  16rpm/27rpm/40rpm/80rpm/160rpm/260rpm/470rpm

Wirings:

Red Wire - positive power supply of motor(+)

Black Wire - negative power supply of motor(-)

Green Wire - negative power supply of encoder(-) (positive and negative power supply of encoder do not allow connect wrong;

Blue Wire - positive power supply of encoder(+) (positive and negative power supply of encoder do not allow connect wrong,(5-12v)

Yellow Wire - signal feedback (11 signals per motor turns a circle)

White Wire - signal feedback (11 signals per motor turns a circle)
